Memo Process
Control 3 Retrofit

An outdated supervisor running on DOS and floppy disk is a liability you can’t afford. The MPC3R replaces obsolete hardware with a last-generation Siemens Microbox: same operator interface, smarter memory, and a direct line to BOBST support.

See if your machine qualifies

Obsolescence Has a Cost. A Retrofit Doesn't Have To.

In today’s automated manufacturing environment, one outdated component can bring your entire line to a halt. Legacy supervisor systems running on unsupported hardware mean no spare parts, no manufacturer backing, and an unpredictable production schedule.

The MPC3R replaces your existing supervisor with a last-generation Siemens Microbox, bringing your FFG or DRO machine in line with the latest MPC3 interface: the same system fitted to new machines today.

The hardware changes. Your workflow doesn’t.

Why Upgrade to MPC3R

Keep Production Moving

Stay ahead of unplanned downtime by eliminating reliance on unsupported hardware—before a failure forces your hand.

Smarter Memory, Better Output

No limitations on programs or settings. Save and reuse operator settings, back up box configurations to USB in seconds, and manage programmable register adjustments with ease.

A Familiar Interface

The MPC3R delivers the same visual and programming interface as the latest MPC3 on new machines; operators work confidently from day one, with no retraining required.

Direct Access to Expert Support

The MPC3R is connect-ready for BOBST Helpline solutions, giving your team faster, more efficient remote assistance when you need it most.

Product Specifications

Eligible Equipment

Applicable for flexo folder gluer and rotary die‑cutter machines equipped with the following supervisors: MP1, MP2, MP3, MTT, MPC1, MPC2, MPC2I, MPC2R — Reference OBS021.

Installation Time

  • Machine downtime: 3–6 days
  • BOBST Field Service Technician on-site: 6–8 days
  • Customer technician required: 2 days
  • 1 day of prior expertise required before order can be placed
An outdated supervisor running on DOS and floppy disk is a liability you can’t afford. The MPC3R replaces obsolete hardware with a last-generation Siemens Microbox: same operator interface, smarter memory, and a direct line to BOBST support.

What the MPC3R Retrofit Does

Hardware Replacement

  • Existing PC rack with DOS software and floppy disk removed entirely
  • Replaced with a brand-new Siemens Microbox and updated operating system
  • USB port included, replacing legacy storage with fast, reliable backup capability
  • Fits directly into the existing control console; no modifications required

Remote Support Connectivity

  • MPC3R is connect-ready for BOBST Helpline
  • Enables faster, more efficient remote assistance from BOBST engineers
  • Reduces diagnosis and resolution time for technical issues

Operator Interface

  • Delivers the same visual and programming interface as the current MPC3 version
  • New touchscreen display improves visibility and navigation
  • Operators interact with the system exactly as they would on a new machine
  • No retraining needed—productivity is maintained from day one

Memory & Settings Management

  • No limitation on the number of programs or saved settings
  • Operator settings can be saved and reused across production runs
  • Programmable adjustment of registers supported
  • Full box settings backed up quickly to USB flash drive

Related Products

One Retrofit for a Longer, More Reliable Machine Life

The MPC3R isn’t just a hardware swap. It’s also a strategic move against obsolescence.

By bringing your flexo folder gluer or rotary die‑cutter machine’s supervisor system up to current MPC3 standards, you protect your production, extend your equipment’s lifecycle, and gain access to the support infrastructure that keeps modern lines running.

Let’s Build Your Upgrade Plan

Our team will assess your current setup, confirm eligibility, and map out a retrofit that minimizes disruption to your operation.
